Intel Xeon Phi Processor 7210F 16GB 1.30GHz 64-core SR2X5 867304-001 Open Box

• HP P/N: 867304-001
• Model: Intel XEON PHI 7210F
• SR2X5

Open Box Intel Xeon Phi Processor 7210F 1.30Ghz 64-Core SR2X5

HP P/N: 867304-001

Product Collection

Intel Xeon Phi℠x200 Product Family

Code Name

Products formerly Knights Landing

Vertical Segment

Server

Processor Number

7210F

Launch Date

Q4'16

Lithography

14 nm

Recommended Customer Price

$2036.00

Performance Specifications

Total Cores

64

Processor Base Frequency

1.30 GHz

Max Turbo Frequency

1.50 GHz

Cache

32 MB L2 Cache

TDP

230 W

VID Voltage Range

0.550-1.125V

Supplemental Information

Description

Intel Xeon Phi processors do not currently support Virtualization. Intel is working with interested OEMs, customers, and the virtualization developer community in providing them with Virtualization feature at a later date.

Memory Specifications

Max Memory Size (dependent on memory type)

384 GB

Memory Types

DDR4-2133

Max # of Memory Channels

6

Max Memory Bandwidth

102 GB/s

ECC Memory Supported

Yes

Expansion Options

PCI Express Revision

3.0

PCI Express Configurations

x16 port (Port 2 and 3) may negotiate down to x8, x4, x2, or x1. x4 port (Port1) may negotiate down to x2, or x1

Max # of PCI Express Lanes

4

Package Specifications

Sockets Supported

SVLCLGA3647

Advanced Technologies

Intel Turbo Boost Technology

2.0

Intel 64

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel AVX-512
